Silent Wave Motor
AF-S NIKKOR lenses feature Nikon’s Silent Wave Motor (SWM), which represents a significant advance in AF lens technology. SWM uses ultrasonic vibrations—rather than a gear system—to
focus the lens, providing incredibly smooth, silent and precise autofocus operation.
ED (Extra-Low Dispersion) Glass
An optical glass developed by Nikon that is used with normal optical glass in telephoto lenses to obtain optimum correction of chromatic aberrations.
AS
AS stands for Aspherical lens elements. This type of lens utilizes non-spherical surfaces on either one or both sides of the glass in order to eliminate certain types of lens aberration.
M/A
Select NIKKOR lenses have a focusing mode which allows switching from automatic to manual focusing with virtually no lag time by simply turning the focusing ring on the lens. This
makes it possible to seamlessly switch to fine manual focusing while looking through the viewfinder.
IF Lens
A NIKKOR lens in which only the internal lens group shifts during focusing. Thus, IF NIKKORS do not change in size during AF operation, allowing for compact, lightweight lenses capable
of closer focusing distances. These lenses will be designated with the abbreviation IF on the lens barrel.
Specifications
-
Mount Type
Nikon F-Bayonet
-
Focal Length Range
10-24mm
-
Zoom Ratio
2.4x
-
Maximum Aperture
f/3.5
-
Minimum Aperture
f/22
-
Format
DX
-
Maximum Angle of View (DX-format)
109°
-
Minimum Angle of View (DX-format)
61°
-
Maximum Reproduction Ratio
0.20x
-
Lens Elements
14
-
Lens Groups
9
-
Compatible Format(s)
DX
FX in DX Crop Mode
-
Diaphragm Blades
7
-
Distance Information
Yes
-
ED Glass Elements
2
-
Aspherical Elements
3
-
Super Integrated Coating
Yes
-
Autofocus
Yes
-
AF-S (Silent Wave Motor)
Yes
-
Internal Focusing
Yes
-
Minimum Focus Distance
0.79 ft. (0.24m)
-
Focus Mode
Auto
Manual
Manual/Auto
-
G-type
Yes
-
Filter Size
77mm
-
Accepts Filter Type
Screw-on
-
Approx. Dimensions (Diameter x Length)
3.25 in. (82.5 mm) x 3.42 in. (87 mm)
-
Approx. Weight
16.2 oz. (460 g)
-
Supplied Accessories
- HB-23 Hood
- CL-1118 Soft Lens Case
- 77mm Lens cap
- Rear lens cap
*Supplied accessories may differ depending on country or area.
