| Image Device |
1/2.88" ExmorR CMOS with ClearVid pixel array |
| Picture Elements |
1920 x 1080 (Effective) |
| Lens |
3.8-38mm (10x) Zoom (26.3-263mm 35mm equivalent) 14x Extended Zoom, 120x Digital Zoom f/1.8-3.4 37mm Filter Thread |
| Focus |
Manual and Auto |
| Stabilization |
Optical SteadyShot w/Active Mode |
| Signal-to-Noise Ratio |
Not specified by manufacturer |
| Minimum Illumination |
3 lx (Low LUX mode, 1/25 shutter) |
| Signal System |
NTSC |
| Built-in Filters |
None |
| LCD Monitor |
3.5"-type, XtraFine Touchscreen LCD 921,600 dots (1920 x 480), 16:9 aspect |
| Speaker |
Mono |
| Viewfinder |
0.45" (16:9) 1,226,880 dots equivalent (852 x 3[RGB] x 480) |
| Shutter Speed |
1/6 - 1/10000 (Manual Shutter Speed Control) |
| White Balance |
Auto, Outdoor (5800K), Indoor (3200K), One-push (Touch panel) |
| Memory Card Slot |
SD/SDHC/SDXC / Memory Stick (x1) |
| Recording Format |
HD: MPEG4-AVC/H.264 AVCHD SD: MPEG-2 PS |
| Frame Rates |
PS (28 Mbps) 1920 x 1080/60p FX (24 Mbps) 1920 x 1080/60i FH (17 Mbps) 1920 x 1080/60i HQ (9 Mbps) 1440 x 1080/60i LP (5 Mbps) 1440 x 1080/60i FX (24 Mbps) 1920 x 1080/24p FH (17 Mbps) 1920 x 1080/24p Slow & Quick Motion Function: 200fps (fixed) as Smooth Slow Rec (Picture quality is degraded) |
| Recording/Playback Time |
170 min (Memory Stick 32GB, HD FX, LPCM) 530 min (Internal memory 96GB, HD FX, LPCM) |
| Audio Dynamic Range |
Not specified by manufacturer |
| Audio Signal Format |
HD: Linear PCM/Dolby Digital 2ch, 16 bit, 48 kHz STD: Dolby Digital 2ch, 16 bit, 48 kHz |
| Input and Output Connectors |
HDMI: HDMI Mini (x1 Output) Component: RCAx3 (x1 Output) Composite: RCA (x1 Output) Line/Mic: 3-pin XLR (x2 Input) Audio: 3.5mm Stereo Jack (x1 Input), RCAx2 (x1 Output) USB: Mini-AB/Hi-Speed (x1) Headphone: 3.5mm Stereo Mini (x1 Output) Remote: LANC type via AV Remote Multi-Pin Connector (x1) |
| Power Requirements |
8.4V AC Adapter / 6.8VDC Battery |
| Power Consumption |
3.5W |
| Operating Temperature |
32° to 104°F (0° to 40°C) |
| Dimensions (WxHxD) |
4.5 x 4.75 x 11.75" (11.2 x 12 x 29.75 cm) (w/hood, eyecup) 5.3 x 6.9 x 15.25" (13.5 x 17.4 x 38.5 cm) (+ battery, mic, XLR unit) |
| Weight |
1.85 lbs (0.84kg) (w/hood, eyecup) 2.85 lbs (1.29kg) (+ battery, mic, XLR unit) |
