| SENSOR SECTION | Image Sensor |
1/3.1-inch BSI MOS Sensor |
| Effective Pixels |
6.03 megapixels [16:9] |
| LENS SECTION | F Value |
F1.8 ― F3.6 |
| Optical Zoom |
20x |
| Focal Length |
4.08 ― 81.6 mm |
| 35 mm Film Camera Equivalent (Motion Image/Still Image) |
29.5 ― 612 mm [16:9] |
| Filter Diameter |
49 mm |
| Lens Brand |
Panasonic Lens |
| CAMERA SECTION | Standard Illumination |
1400 lx |
| Minimum Illumination |
1.2 lx (Super Gain 36dB, Shutter 1/25) |
| Focus |
Auto / Manual |
| Zoom | Intelligent Zoom OFF |
20x |
| Intelligent Zoom ON |
40x |
| Digital Zoom |
2x / 5x / 10x |
| White Balance |
Auto / 3200K / 5600K / VAR (2000K—15000K) / Ach Fixed / Bch Fixed |
| Shutter Speed |
1/6 — 1/8000 |
| Shutter Speed |
Super Slow: 1/100 — 1/8000 |
| Iris |
Auto / Manual |
| Image Stabilizer |
5-axis HYBRID O.I.S.+ with Level Shot Function |
| RECORDING SECTION | Recording Media |
SDHC/SDXC Memory Card |
| Recording Format |
MOV / MP4 |
| Recording Format |
AVCHD: AVCHD Progressive |
| Video Compression Method |
MPEG-4 AVC/H.264 |
| Audio Compression Method |
MOV: LPCM (2ch) |
| Audio Compression Method |
MP4: LPCM (2ch) |
| Audio Compression Method |
AVCHD: Dolby Digital (2ch) |
| System Frequency |
50.00Hz |
| Recording / Playback Mode | MP4 |
1920x1080 50p 50M: Average 50Mbps (VBR), LPCM |
| MP4 |
1920x1080 50i 50M: Average 50Mbps (VBR), LPCM |
| MP4 |
1920x1080 25p 50M: Average 50Mbps (VBR), LPCM |
| MOV |
1920x1080 50p 50M: Average 50Mbps (VBR), LPCM |
| MOV |
1920x1080 50i 50M: Average 50Mbps (VBR), LPCM |
| MOV |
1920x1080 25p 50M: Average 50Mbps (VBR), LPCM |
| AVCHD |
PS 1080 50p: 1920x1080, Max. 28Mbps (VBR) |
| AVCHD |
PH 1080 50i: 1920x1080, Max. 24Mbps (VBR) |
| AVCHD |
HA 1080 50i: 1920x1080, Average 17Mbps (VBR) |
| AVCHD |
HE 1080 50i: 1440x1080, Average 5Mbps (VBR) |
| AVCHD |
PM 720 50p: 1280x720, Average 8Mbps (VBR) |
| AVCHD |
SA 576 50i: 720x576 (SIDE CROP/SQUEEZE), Average 9Mbps (VBR) |
| Thumbnail Display |
20 thumbnails/page, 9 thumbnails/page, 1 thumbnail/page |
| Microphone |
Stereo Microphone |
| Speaker |
Dynamic type |
| STILL IMAGE SECTION | Recording Format |
JPEG (DCF/Exif2.2) |
| Recording Image Size |
Recording Mode: [16:9] 2.1 megapixels (1920 x 1080), 0.2 megapixels (640 x 360, [4:3] 0.3 megapixels (640 x 480) |
| Recording Image Size |
Playback Mode: [16:9] 2.1 megapixels (1920 x 1080), 0.9 megapixels (1280 x 720) |
| Flash |
— |
| GENERAL SECTION | Power Supply |
7.2V (Battery) / 12V (AC Adaptor) |
| Power Consumption |
11.7W (Recording) / 27.4W (Charging) |
| Dimensions (W x H x D) |
Approx. 170 x 170 x 335 mm (6.69 x 6.69 x 13.2 inch) |
| Weight (w/o Battery and SD Card) |
Approx. 1500g (3.31 lb) |
| LCD Monitor |
3.0-inch Wide LCD monitor (Approx. 460K dots) |
| Viewfinder |
0.24-inch Wide EVF (Approx. 1,555K dots equivalent) |
| Manual Ring |
Focus / Zoom / Iris |
| Interface | AV |
Yes |
| HDMI |
Type A |
| XLR Input |
XLR (3 pins) x 2 |
| XLR Input |
Line:0dBu/+4dBu, Mic:-40dBu/-50dBu/-60dBu |
| Headphone |
Yes (3.5mm stereo mini) |
| USB |
Micro-B: USB 2.0 Hi-Speed, Mass Storage Function (read only) |
| USB |
Type A: USB 2.0 Hi-Speed, for External Media Device Connection*, Bus Power Supply |
| Camera Remote |
2.5mm super mini jack x 1 (ZOOM S/S) |
| Camera Remote |
3.5mm mini jack x 1 (FOCUS/IRIS) |
| LED Video Light | Average Illumination |
Approx. 300 lx (1.0m) |
| Irradiation Angle |
Approx. 30° |
| Color Temperature |
Approx. 5000K |
| Average Illumination with Diffusion Filter |
Approx. 70 lx (1.0m) |
| Color Temperature with Color Conversion Filter |
Approx. 3000K |
| Accessory Shoe |
Yes |
| Wi-Fi | Standard |
— |
| Frequency |
— |
| NFC |
— |
| STANDARD ACCESSORY | AC Adaptor |
Yes |
| AC Cable |
Yes |
| Rechargeable Battery Pack |
Yes (2,900mAh) |
| Battery Charger |
— |
| IR Remote |
— |
| HDMI Cable |
— |
| AV Multi Cable |
— |
| AV Cable |
Yes |
| Shoe adaptor |
— |
| USB Cable |
— |
| Microphone Holder |
Yes |
| Microphone Holder Screws |
Yes (2 Screws) |
| Input Terminal Cap |
Yes (2 Caps) |
| Shoulder Strap |
— |
| Eye Cup |
Yes |
| Lens Cap |
Yes |
| LED Light Filter |
Difusion Filter / Color Conversion Filter |
| Editing Software |
— |
| NOTE |
*External media device with a capacity of 32 GB or less, or more than 2 TB, cannot be used. |
| NOTE |
Specifications are subject to change without notice |
