The Samyang 24mm T1.5 Cine Lens was developed primarily for film and video applications. The cine version of Samyang's 24mm lens features industry-standard gearing for the focus and aperture ring, and the aperture ring has been "declicked" for smooth iris pulls. The aperture and focus scales have also been relocated to the side of the lens, where it is easier for focus pullers to read them.
The Samyang 24mm cine lens is compatible with full-frame sensors. APS-C sensors with a crop factor of 1.5 - 1.6 will exhibit a 35mm equivalent angle-of-view equal to approximately 38mm. The optical construction is comprised of 13 lenses arranged in 12 groups. Four lenses are low-dispersion glass (ED), plus two aspheric elements. The 24mm features Ultra Multi Coated (UMC) multi-coated lenses for improved light transmission and resistance to ghosting and flares.
General
Aperture
(F) Maximum Aperture |
1.50 |
(F) Minimum Aperture |
22 |
Aperture Ring |
No |
Number of Diaphragm Blades |
8 |
Optics
Focus
Minimum Focus (m) |
0.25 |
Autofocus |
No |
Full time Manual |
No |
Focus Method |
No |
Distance Scale |
No |
DoF Scale |
No |
Physical
Diameter (mm) |
83 |
Length (mm) |
87.5 |
Sealing |
No |
Power zoom |
No |
zoom_lock |
No |
Hood Supplied |
No |
Tripod Collar |
No |
Tripod Supplied |
No |
